Afore Commercial&Power Plants BNT Series BNT003KTL Three-phase String PV Inverter

Afore Commercial&Power Plants BNT Series BNT003KTL Three-phase String PV Inverter
Afore Commercial&Power Plants BNT Series BNT003KTL Three-phase String PV Inverter
Afore Commercial&Power Plants BNT Series BNT003KTL Three-phase String PV Inverter

Afore Commercial&Power Plants BNT Series BNT003KTL Three-phase String PV Inverter

Afore Three Phase String 3000W On-grid PV Inverter For Home Using And Primary Comercial & Industry

PV Input Data BNT003KTL BNT004KTL BNT005KTL BNT006KTL BNT008KTL BNT010KTL
Max. DC Power ( W ) 5100 6000 7500 9000 12000 15000
Max. DC Voltage ( V ) 1100
MPPT Voltage Range ( V ) 150-1000
MPPT Full Power Voltage Range ( V ) 200-850 250-850 300-850 500-850
Rated Input Voltage ( V ) 620
Start-up Voltage ( V ) 150
Max. Input Current ( A ) 15x2
Max. Short Current ( A ) 25x2
No. of MPP Tracker /No. of PV String 2/2
Input Connector Type MC4
Inquire Now

Advantages of Afore Three-phase On-grid Inverter

  • Quick Arc Fault circuit interruption (Optional)
  • WIFI standard
  • Compact design
  • Multiple intelligent protections
  • Compatible with bifacial modules
  • String level monitoring
General Data BNT003KTL BNT004KTL BNT005KTL BNT006KTL BNT008KTL BNT010KTL
Dimensions (H x W x D, mm) 510 x 370 x 167 510 x 370 x 192
Weight ( kg ) 16 15
Protection Degree IP65
Enclosure Material Aluminum
Ambient Temperature Range (°C ) -25 to 60
Humidity Range 0-100%
Topology Transformerless
Communication Interface RS485 / WiFi / Wire Ethernet / GPRS (optional)
Cooling Concept Convection Intelligent fan cooling
Noise Emission ( db ) <30
Night Power Consumption ( W ) <1
Max. Operation Altitude ( m ) ≤4000



Hot Tags : solar inverter 3 phase 3000w solar inverter grid tied solar inverter 3kw solar inverter solar inverter price custom reasonable price solar inverter price
